CoLink® PCR

Carbon Fiber Reinforced Plating System

The first plate implants were made from steel. Then came stainless steel and titanium alloy.
Carbon Fiber Reinforced PEEK is the New Revolution!

key feature icon

Next Generation Technology

Designed for high fatigue strength and reduced cold weld concerns

key feature icon

Fixation
Options

MTP Fusion Plates come in neutral and 4° dorsiflexion versions

key feature icon

Improved Visualization

Invisible on X-ray, so you can see more of the bone

colink pcr product and xrays

The CoLink® PCR1 Plates utilize a unique carbon fiber reinforced PEEK polymer - a next generation metal-free technology with long carbon fibers layered in alternating directions for enhanced properties that result in high fatigue strength. The orientation of the fibers is customized to enhance the performance of the plating system.

Since the plates are invisible on X-ray, with Barium sulfate added for slight visibility, experience radiolucent artifact-free imaging.


An Implant Material Engineered to Last

The CoLink® PCR Plate's increased fatigue strength means that the implant can withstand a higher repetitive load (more than 2.5x higher than its Titanium Alloy counterpart) at the same number of loading cycles (steps).2

colink-pcr-fatigue-strength-comparison-chart

Plate options include the CoLink® PCR 0° and 4° Narrow MTP Plates and the CoLink® PCR 2-6 Hole Universal Plates. CoLink® 3.0mm or 3.5mm locking or non-locking plate screws can be used. A reusable instrument set is available, as well as the CoLink® dense bone sterile disposable instrument set.


Designed for Better, Safer, Optimized Procedures

Earlier Callus Formation and Return to Function

A less stiff material produces greater callus formation3

Enhanced View of Healing Site

Radiolucency and artifact-free imaging provides more accurate assessment during healing4

Easier Revisions, When Necessary

Reduced tissue adhesion and bone ongrowth with no cold welding of screws enables easier hardware removal3


1 Manufactured by Invibio (PEEK-OPTIMA Ultra-Reinforced).
2 Data on file at In2Bones. Testing data is specific to the CoLink PCR MTP Plate. Mechanical Benchmark of Carbon Fiber PEEK-OPTIMA Ultra-Reinforced vs Ti 6AI-4V Plates undergoing Static and Dynamic Testing per ASTM F382-99 (2008).
3 Tarallo L, Mugnai R, Adani R, Zambianchi F, Catani F, A New Volar Plate made of Carbon-Fiber-Reinforced Polyetheretherketone for Distal Radius Fracture: Analysis of 40 Cases, J Orthop Traumatol, 2014 Dec; 15(4): 277-83.
4 Jo Wilson, PhD, Matthew Cantwell; Polyether Ether Ketone (PEEK) Carbone Fiber Composites May Improve Healing of Fractures Stabilized with Intramedullary Nails. (Basic Science Focus Forum, paper #4, 2014) 155.

Documents and Specifications

Instrumentation

CAT#
P06 N0021
5MS® T7 DRIVER BIT - SOLID - AO - 2.4/2.7 5MS® SCREWS
CAT#
P06 N0031
5MS® T15 DRIVER BIT - CANNULATED - 4.5 JONES SCREWS
CAT#
P06 N0041
5MS® T25 DRIVER BIT - CANNULATED - 5.5 & 6.0 JONES SCREWS
CAT#
P06 S0021
5MS® T7 DRIVER BIT - SOLID - AO - STERILE - 2.4/2.7 5MS® SCREWS
CAT#
P06 S0031
5MS® T15 DRIVER BIT - CANNULATED - 4.5 JONES SCREWS - STERILE
CAT#
P06 S0041
5MS® T25 DRIVER BIT - CANNULATED - 5.5 & 6.0 JONES SCREWS - STERILE

Plate (Plantar)

CAT#
P60 ST011
5MS® PLANTAR PLATE, 5-HOLE - STERILE
CAT#
P60 ST012
5MS® PLANTAR PLATE, 4-HOLE - STERILE
CAT#
P60 ST021
5MS® PLANTAR PLATE, LARGE, 5-HOLE - STERILE
CAT#
P60 ST022
5MS® PLANTAR PLATE, LARGE, 4-HOLE - STERILE

Plate (Lateral Neck)

CAT#
P60 ST031
5MS® LATERAL NECK PLATE, 8-HOLE, RIGHT - STERILE
CAT#
P60 ST032
5MS® LATERAL NECK PLATE, 6-HOLE, RIGHT - STERILE
CAT#
P60 ST033
5MS® LATERAL NECK PLATE, 8-HOLE, RIGHT - STERILE
CAT#
P60 ST034
5MS® LATERAL NECK PLATE, 6-HOLE, LEFT - STERILE

Plate (Bunionette)

CAT#
P60 ST041
5MS® BUNIONETTE PLATE, 5-HOLE, RIGHT - STERILE
CAT#
P60 ST042
5MS® BUNIONETTE PLATE, 4-HOLE, R/L - STERILE
CAT#
P60 ST043
5MS® BUNIONETTE PLATE, 5-HOLE, LEFT - STERILE

Plate (Pseudo Jones)

CAT#
P60 ST050
5MS® PSEUDO JONES HOOK PLATE - STERILE
CAT#
P60 ST051
5MS® PSEUDO JONES HOOK PLATE, LONG - STERILE

2.4mm Non-Locking Screws

CAT#
P62 ST408
5MS® PLATE SCREW, 2.4 X 8MM, NON-LOCKING - STERILE
CAT#
P62 ST409
5MS® PLATE SCREW, 2.4 X 9MM, NON-LOCKING - STERILE
CAT#
P62 ST410
5MS® PLATE SCREW, 2.4 X 10MM, NON-LOCKING - STERILE
CAT#
P62 ST411
5MS® PLATE SCREW, 2.4 X 11MM, NON-LOCKING - STERILE
CAT#
P62 ST412
5MS® PLATE SCREW, 2.4 X 12MM, NON-LOCKING - STERILE
CAT#
P62 ST413
5MS® PLATE SCREW, 2.4 X 13MM, NON-LOCKING - STERILE
CAT#
P62 ST414
5MS® PLATE SCREW, 2.4 X 14MM, NON-LOCKING - STERILE
CAT#
P62 ST415
5MS® PLATE SCREW, 2.4 X 15MM, NON-LOCKING - STERILE
CAT#
P62 ST416
5MS® PLATE SCREW, 2.4 X 16MM, NON-LOCKING - STERILE
CAT#
P62 ST418
5MS® PLATE SCREW, 2.4 X 18MM, NON-LOCKING - STERILE
CAT#
P62 ST420
5MS® PLATE SCREW, 2.4 X 20MM, NON-LOCKING - STERILE
CAT#
P62 ST422
5MS® PLATE SCREW, 2.4 X 22MM, NON-LOCKING - STERILE

2.7mm Non-Locking Screws

CAT#
P62 ST708
5MS® PLATE SCREW, 2.7 X 8MM, NON-LOCKING - STERILE
CAT#
P62 ST709
5MS® PLATE SCREW, 2.7 X 9MM, NON-LOCKING - STERILE
CAT#
P62 ST710
5MS® PLATE SCREW, 2.7 X 10MM, NON-LOCKING - STERILE
CAT#
P62 ST711
5MS® PLATE SCREW, 2.7 X 11MM, NON-LOCKING - STERILE
CAT#
P62 ST712
5MS® PLATE SCREW, 2.7 X 12MM, NON-LOCKING - STERILE
CAT#
P62 ST713
5MS® PLATE SCREW, 2.7 X 13MM, NON-LOCKING - STERILE
CAT#
P62 ST714
5MS® PLATE SCREW, 2.7 X 14MM, NON-LOCKING - STERILE
CAT#
P62 ST715
5MS® PLATE SCREW, 2.7 X 15MM, NON-LOCKING - STERILE
CAT#
P62 ST716
5MS® PLATE SCREW, 2.7 X 16MM, NON-LOCKING - STERILE
CAT#
P62 ST718
5MS® PLATE SCREW, 2.7 X 18MM, NON-LOCKING - STERILE
CAT#
P62 ST720
5MS® PLATE SCREW, 2.7 X 20MM, NON-LOCKING - STERILE
CAT#
P62 ST722
5MS® PLATE SCREW, 2.7 X 22MM, NON-LOCKING - STERILE
CAT#
P62 ST724
5MS® PLATE SCREW, 2.7 X 24MM, NON-LOCKING - STERILE

2.4mm Screws

CAT#
P64 ST408
5MS® PLATE SCREW, 2.4 X 8MM, LOCKING - STERILE
CAT#
P64 ST409
5MS® PLATE SCREW, 2.4 X 9MM, LOCKING - STERILE
CAT#
P64 ST410
5MS® PLATE SCREW, 2.4 X 10MM, LOCKING - STERILE
CAT#
P64 ST411
5MS® PLATE SCREW, 2.4 X 11MM, LOCKING - STERILE
CAT#
P64 ST412
5MS® PLATE SCREW, 2.4 X 12MM, LOCKING - STERILE
CAT#
P64 ST413
5MS® PLATE SCREW, 2.4 X 13MM, LOCKING - STERILE
CAT#
P64 ST414
5MS® PLATE SCREW, 2.4 X 14MM, LOCKING - STERILE
CAT#
P64 ST415
5MS® PLATE SCREW, 2.4 X 15MM, LOCKING - STERILE
CAT#
P64 ST416
5MS® PLATE SCREW, 2.4 X 16MM, LOCKING - STERILE
CAT#
P64 ST418
5MS® PLATE SCREW, 2.4 X 18MM, LOCKING - STERILE
CAT#
P64 ST420
5MS® PLATE SCREW, 2.4 X 20MM, LOCKING - STERILE
CAT#
P64 ST422
5MS® PLATE SCREW, 2.4 X 22MM, LOCKING - STERILE

2.7mm Screws

CAT#
P64 ST708
5MS® PLATE SCREW, 2.7 X 8MM, LOCKING - STERILE
CAT#
P64 ST709
5MS® PLATE SCREW, 2.7 X 9MM, LOCKING - STERILE
CAT#
P64 ST710
5MS® PLATE SCREW, 2.7 X 10MM, LOCKING - STERILE
CAT#
P64 ST711
5MS® PLATE SCREW, 2.7 X 11MM, LOCKING - STERILE
CAT#
P64 ST712
5MS® PLATE SCREW, 2.7 X 12MM, LOCKING - STERILE
CAT#
P64 ST713
5MS® PLATE SCREW, 2.7 X 13MM, LOCKING - STERILE
CAT#
P64 ST714
5MS® PLATE SCREW, 2.7 X 14MM, LOCKING - STERILE
CAT#
P64 ST715
5MS® PLATE SCREW, 2.7 X 15MM, LOCKING - STERILE
CAT#
P64 ST716
5MS® PLATE SCREW, 2.7 X 16MM, LOCKING - STERILE
CAT#
P64 ST718
5MS® PLATE SCREW, 2.7 X 18MM, LOCKING - STERILE
CAT#
P64 ST720
5MS® PLATE SCREW, 2.7 X 20MM, LOCKING - STERILE
CAT#
P64 ST722
5MS® PLATE SCREW, 2.7 X 22MM, LOCKING - STERILE
CAT#
P64 ST724
5MS® PLATE SCREW, 2.7 X 24MM, LOCKING - STERILE
